CS/OL3型多功能照準器
CS/OL3型多功能照準器
The CS/OL3 multifunctional sight
裝備概述
CS/OL3型多功能照準器可加裝在具有皮卡汀尼導軌的自動步槍、短自動步槍、精準步槍上，也可手持使用。具有強光照射和激光照準功能，主要用于強光照射及強光致眩、夜間弱光照明、光信號聯絡和夜間（或低照度條件下）近距離激光快速瞄準。
Summary
The CS / OL3 multifunctional sight can be mounted on automatic rifles, short automatic rifles, precision rifles with Picatinny rails, and can also be used handheld. With strong light irradiation and laser collimation functions, it is mainly used for strong light irradiation and glare-induced glare, low-light illumination at night, light signal communication and short-range laser rapid aiming at night (or under low light conditions).
技術參數
項目(mu)名稱 | 技術參數 | |
激光瞄準 | 波(bo)長 | 532 nm |
出射(she)功(gong)率 | ≤5 mw | |
FDA安全等級 | IIIa | |
束散角 | ≤1 mrad | |
工作距(ju)離 | ≥150米（背景照(zhao)度≤1Lux） | |
白光LED照明 | 照度 | ≥300 Lum |
光照度 | 強光照射25米中心光斑照度≥5 Lux | |
光斑(ban)直徑 | ≥2.5米(mi)（25米(mi)距離，邊界照度(du)≥3.5Lux） | |
LED紅、綠信號燈 | 光信(xin)號可見距離 | 500米(mi)（紅色(se)、綠色(se)，無月星空） |
供電電池 | 1節CR18650（有反極性保護(hu)功(gong)能(neng)） | |
放電壽(shou)命 | LED燈≥1小時，激光器（532nm）≥5小時 | |
工作電壓 | 3.6 V~4.2 V | |
低電壓報警 | 3V（低(di)于2.5V關機） | |
工作溫度 | -40℃～+50℃ | |
儲藏溫度 | -50℃～+60℃ | |
環境濕度(du) | ≤90％ | |
光源工(gong)作壽命 | ≥8000小時 | |
防水 | IP67 | |
尺寸 | 106.2 mm×70 mm×36.3 mm（長×寬×高） | |
重量 | ≤0.32kg（含電池(chi)、連(lian)接座(zuo)） | |
Main specifications
Project Name | Technical Parameters | |
Laser aiming | Wavelength | 532 nm |
Output power | ≤5 mw | |
FDA safety rating | IIIa | |
Beam divergence angle | ≤1 mrad | |
Working distance | ≥150 meters (background illumination ≤1Lux) | |
White LED lighting | Illumination | ≥300 Lum |
Illumination (no moon starry sky) | 25m center light spot illumination with strong light ≥5 Lux | |
Spot diameter | ≥2.5 meters (25 meters distance, border illumination ≥3.5Lux) | |
LED red and green signal lights | Visible distance of optical signal | 500 meters (red, green, moonless starry sky) |
Battery | One CR18650 (with reverse polarity protection function) | |
Discharge life | LED lights≥1hour，Laser（532nm）≥5hours | |
Operating Voltage | 3.6 V~4.2 V | |
Low voltage alarm | 3V（Shut down below 2.5V） | |
Operating temperature | -40℃～+50℃ | |
Stored temperature | -50℃～+60℃ | |
Environment humidity | ≤90％ | |
Light source working life | ≥8000hours | |
Waterproof rating | IP67 | |
Size | 106.2 mm×70 mm×36.3 mm（Length x width x height） | |
Weight | ≤0.32kg（With battery, connector） | |
